Quick Details

  • Condition: New
  • Type: Paper Folding Machine
  • Computerized: Yes
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Victory
  • Model Number: SZB
  • Voltage: 220V/380V
  • Power(W): 4.5Kw
  • Dimension(L*W*H): 2500*1300*1700mm
  • Weight: 1400Kg
  • Certification: CE.ISO,SGS etc.
  • Warranty: 1 year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Name: disposable cup forming machine
  • Product name: disposable cup forming machine

Packaging & Delivery

Packaging Details The disposable cup forming machine will be packaged with export standard wooden case.
Delivery Time 20days when make sure the paper coffee cup making machine
Product Description

 disposable cup forming machinee

This machine is developed on the original basis, and enjoy the high-speed automatic paper cup shaper of two national patent.


CE Standard SZB/W Single Side PE Paper Cup Forming Machine

That machine is developed on the original basis, and enjoys the high-speed automatic paper cup shaper of two national patents. It is the idea equipment of producing paper cup and other food package machine. It enjoys light, convenience, save electricity and utility etc. This machine runs a whole procedure of paper feeding, body sealing, oiling, bottom punching, heating, knurling, curling, cup discharge and cup counter.


Main Technical Parameter

ModelSZB/W-9SZB/W-12SZB/W-18 (Special model)SZB/W-32 (Special model)
Production capacity45-55PCS/min40-50PCS/min35-45PCS/min30-40PCS/min
Required paper150-320gsm Single Side PE Paper150-320gsm Single Side PE Paper150-320gsm Single Side PE Paper150-320gsm Single Side PE Paper
Cup' s Range(A) 50 -80MM, (B)35-90MM (C) 35-55MM, (D)4 -10 MM(A) 50 -90MM, (B)35-115MM (C) 35-70MM, (D)5 -10 MM(A) 60 -128MM, (B)80 -140MM (C) 50 -75MM, (D)5 -10 MM(A) 60 -128MM, (B)80 -180MM (C) 50 -75MM, (D)5 -10 MM
Total power220/380V 50/60HZ 4.5KW
Weight1400kg1500 kg1700kg1850kg
Overall dimensions (L*W*H)2500*1300* 1700mm2650*1300* 1700mm2850*1300* 1900mm3000*1400* 2000mm


Packaging & Shipping


Our Services

Experienced Sales Team: Our sales team is experienced, and they all know our product well. So we can give you the best service all the time.
